The FreeStyle Libre sensor continuously measures your glucose levels, day and night, without the need for finger pricking1.
This small, discreet and water-resistant2 sensor is worn on the back of your upper arm and lasts for up to 14 days whilst you shower, bathe, swim, exercise or play.
Start using the FreeStyle Libre system in 3 easy steps
The FreeStyle Libre sensor is applied on to the back of the upper arm with a simple, disposable device called an applicator.
When the sensor is applied, a thin, flexible and sterile fibre is inserted just under the skin. It is held in place with a small adhesive pad.
To obtain a glucose reading, simply perform a quick, painless3 1-second scan of the reader over the sensor.
This scan gives you more information than monitoring with blood glucose test strips, without the need for finger pricks1.
Each scan over the sensor gives a current glucose reading, the last 8 hours of glucose history, and a trend arrow showing if glucose is going up, down, or changing slowly8.
Sensor size | 5 mm height and 35 mm diameter |
Sensor weight | 5 grams |
Sensor power source | 1 silver oxide battery |
Sensor life | Up to 14 days |
Sensor memory | 8 hours (glucose reading stored every 15minutes) |
Sensor operating temperature | 10°C to 45°C |
Sensor applicator and sensor pack storage temperature | 4°C to 25°C |
Operating and storage relative humidity | 10%-90%, non-condensing |
Sensor water resistance | IP27: Can withstand immersion into one meter (3 ft) of water up to 30 minutes |
Operating and storage altitude | -381 meters(-1,250 ft) to 3048 meters(10,000 ft) |
How to apply the FreeStyle Libre Sensor
Select an area on the back of your upper arm, avoiding areas with moles, scarring, or recent insulin injections. Select a different site than the one most recently used.
Clean the skin with soap and water, dry the skin, wipe skin with an alcohol swab (let it air-dry) before proceeding. The site selected on the back of the upper arm should be clean-shaven.
The sensor pack and sensor applicator are packaged as a set.
Learn more about the FreeStyle Libre Sensor
Do you have any further questions about FreeStyle Libre?
For further information please contact our Customer Service Team
Images and simulated data for illustrative purposes only. Not real patient or data.
1. Finger pricks are required if glucose readings do not match symptoms or expectations.
2. Sensor is water-resistant in up to 1 meter (3 feet) of water. Do not immerse longer than 30 minutes. Not to be used above 10,000 feet.
3. In a study conducted by Abbott Diabetes Care, 92% of patients surveyed (n=119) patients agree that it was painless or almost painless to apply the sensor.
4. The LibreView website is only compatible with certain operating systems and browsers. Please check www.LibreView.com for additional information.
5. Alva S. et al. 2020. Accuracy of a 14-Day Factory-Calibrated Continuous Glucose Monitoring System With Advanced Algorithm in Pediatric and Adult Population With Diabetes.
6. For a complete glycemic picture scan once every 8 hours.
7. The reader can capture data from the sensor when it is within 1cm to 4cm of the sensor.
8. The Glucose Trend Arrow may not always appear with your reading.
